Automatic Hydraulic Lifing Road Blockers Security Electric Trafict Rising Bollards

Basic Information
Place of Origin: Guangdong
Brand Name: SECUERA
Certification: CE,RSOH
Model Number: ZA-R2
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: International standard package
Supply Ability: 1000/sets/month
Contact Now
Detail Information
Product Name: Automatic Rising Road Blocker Outside Bollard Height: 600 Mm
Rising Bollard Diameter: 219 Mm The Lift Height: 600 Mm ;(Out Box Size:L500 X W500 X H900mm)
Thickness: 6 Mm Control Mode: Remote Control
Weight: 180 Kg Rise Time: 2 ~ 3s
Protection Grade: IP68 Anti-collision Levels: K6

Product Description

Automatic Hydraulic Lifing Road Blockers Security Electric Trafict Rising Bollards



Automatic Rising Road Blocker, Hydraulic Lifing Road Blockers,Road Block Equipment



Description:

  • The automatic Rising Bollard is an electric-hydraulic-mechanically operated retractable bollard system.
  • The system can be quickly and easily operated. It is suitable for both security and access control aplications.
  • The system is designed to bring desired environmental and aesthetic enhancements to perimeter security, securing perimeter access without providing a sense of social disorder and active alarm measures. The system is designed to withstand impacts and still operate, giving high security levels to all sites. It is ideal for university campuses, pedestrian walkways, parking lots, government buildings, sports stadiums, amusement parks, airports, shopping centers, hospitals, and apartment complexes.



Feature:

  • 1. Steady and safe due to the Omron plc control system
  • 2. Speedy and durable due to the use of hydraulic pressure
  • 3. Lower down the bollards by handle valve in case of power failure
  • 4. Raise up the bollards by handle pumpin case the fault of automatic system
  • 5. Bollard is made of 304# Stainless steel. Also Galvanization is durable
  • 6. Optimization of frame structure, high anti-impact& high loading capability,
  • 7. Protecting key avoids mistake operation
  • 8. Max anti-pressure reach to 100 ton truck
  • 9. Working Temperature :from -35℃ to 75℃
  • 10. One control unit to control 2-10pcs bollards at the same time



Technical Parameters:



 Anti-collision levels  K6
 Protection grade  IP68
 Rise time  2 ~ 3s
 Decrease time  2 ~ 3 s
 System dynamic  3.7 KW / 380 v(control unit 24v)
 Outside bollard height  600 mm
 Rising bollard diameter  219 mm
 The lift height  600 mm ;(Out box size:L500 x W500 x H900mm)
 Thickness  6 mm
 Control mode  remote control
 Weight  180 kg

Automatic Hydraulic Lifing Road Blockers Security Electric Trafict Rising Bollards



Automatic Hydraulic Lifing Road Blockers Security Electric Trafict Rising BollardsAutomatic Hydraulic Lifing Road Blockers Security Electric Trafict Rising Bollards
