Anti Collision Automatic Hydraulic Road Blocker , Electric Retractable Rising Bollards

Basic Information
Place of Origin: China
Brand Name: SECUERA
Certification: CE,FCC,ROHS,ISO
Model Number: SERHB-03
Minimum Order Quantity: 1 pic
Price: negotiable
Packaging Details: Wooden Box
Delivery Time: 5-8 workdays
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 10 pic /Month
Contact Now
Detail Information
Warranty: 3 Years Product Name: Rising Hydraulic Bollards
Life: Over 10 Years Material: 304 Stainless Steel
Application: Factory,School,Prison,Car Parking Station And So On Model Number: SERHB-03
Feathers-1: High Security And Anti-collision Ability Feathers-2: Pneumatic Air Pump In Control Cabinet Could Procide Large Power Safely For A Long Time
Feathers-3: Electronic Control, Automatic Rise/fall Feathers-4: High System Independence

Product Description

Special Offer Automatic Hydraulic Electric Retractable Rising Bollards for safety area



rising hydraulic bollards Information

Automatic pneumatic bollard,controlled by electricity,rise/fall automatically.It uses air as power and it is environment-friendly product.It can achieve unfied control,assembled power, and it is easy to operate.With high speed and high impact strength.It belongs to the high-security product.



rising hydraulic bollards Feature

High security and anti-collision ability

Pneumatic air pump in control cabinet could procide large power safely for a long time.

Electronic control, automatic rise/fall

High system independence



rising hydraulic bollards Reflective band

Various color options for Glossee aveolate reflective band; only need weak light to be clearly visible at night.



rising hydraulic bollards Materials Available

304 stainless steel, 316 stainless steel and carbon steel with electrophoresis spray paint.



rising hydraulic bollards Flange

Anti-skid flange with unique some pattern design. Compatible with various road surface styles. Built-in PA orientation.



rising hydraulic bollards Top cap

Its simple integration design is compatible with all kinds of architectural style. Excellent workmanship is amenable to any close attack.



rising hydraulic bollards Basic infomation
Rising time
3s
Dropping time
3s
Packing dimension
φ500*1105mm
Rising height
600mm
Height underground
1105mm
Cylinder dia.
273mm
Cylinder Thickness
6/8/10mm (On request)





rising hydraulic bollards Material
Cylinder
304 Stainless steel
Flange
304 Stainless steel
Flange thickness
10mm
Pre-embedded section
Q235 Steel (A3, Dark grey Spray paint)
Actuator piston rod dia.
18mm
Hydraulic cylinder
304 Stainless steel
Rail
QPQ treatment
Rail dia.
20mm
Reflective tape
30mm(Blue)
LED warning light
RGB, various dynamic mode





rising hydraulic bollards Actuator
Actuator type
Oil-immersed
Lifting force
130kg
Protection rate
IP68
Power supply
220VAC
Power consumption
350W
Max Operating frequency
1.5/min
Working life
30,000 times of trouble-free
Overheating protection
75℃
Heating unit
Optional
Ambient temperature
-40℃~55℃





rising hydraulic bollards Control Center
Control Center
PLC (With display)
Housing
Spray paint (Outdoor use)
Seft-testing program
Yes
Trial period setting
Yes
Warning light Auto ON/OFF
Yes
Emergency rising/dropping
Yes
Emergency dropping once power off
Yes
Remote control
100m
LED remote control
30m, 2.4GHz remote control
Wire switch
Optional





Packaging& Delivery:
1. Packaging: According to Standard Export Packing or as per customers' requirements
2. Delivery: Express/ Air/ Sea/ under the requirements of customer
3. Taxes & duties: International customers are responsible for all duties and taxes,
please contact your local authority for questions related to the amount of duties or taxes
you will be responsible for.



Our services:
1. Securina provides full operational and technical training support by experienced engineers
2. Phone technical support



FAQ

Q: Are you manufacturer or trader?
A:We are manufacturer, we have own factory in Shenzhen, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation, believe our team is best team in china.



Q. Do you sell the accessories for Products ?
A:Yes. We have Match the parts for our testing equipment. If our machines damages by fire, water flood, earthquakes, unsteady of power and other natural disasters, we are willing supply match parts with lowest price for you.



Q.How about the packing for product?
A:Is it easy damaged during transportation? For light structure products like Gold detector. Hand held metal detector and so on we takes of strong carton box . For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case. Every prepackage have a plastic bags cover .



Q. What’s your main product?
A:We professional in needle detector. Metal detector. X ray machine and other related electronic products and machines



Q.Where is your main sales market?
A:Our Gold meal detectors customer all over the world. Our hand metal detector and walk through metal detector mainly in Southeast of Asia. South of America.Middle east. East Europe and Africa Our needle and food metal detector mainly customers are from Australia. USA. All Europe and Asia



Q.How about your after-sales policy?
A:Customer first is our always principle . All of our products normal warranty is 24months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .



Q.Do you accept customer Logo and customized ?
A:we accept kinds of customized and logo of all of our products for customers



Q:How can we contact with you?
A:Whatsapp:+15818573270
Skype&Wechat:secuera88
