Place of Origin: | shenzhen |
---|---|
Brand Name: | SECUERA |
Certification: | CE. ISO |
Model Number: | SE-5030A |
Minimum Order Quantity: | 1 |
Price: | negotiation |
Packaging Details: | Takes of ploy wooden case that suitable delivery by air or by sea High Quility Whole Screen Continuous Observation Security Examined X-ray Baggage Scanner Provided By China Supplies |
Delivery Time: | 5-15days, according to order amount |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 100/per month |
Conveyor Speed: | 0.22 M/s | Tunnel Size: | 300mm(H)*500mm(W) |
---|---|---|---|
Maximum Leak: | <0.3 μGy/H | Wire Resolution: | 0.0787mm Metal Line |
Warranty: | 12 Months | Steel Penetration: | 34mm |
High Light: | baggage scanning machine,airport baggage x ray machines |
Technical Specification
Tunnel Dimension | 300mm(H)*500mm(W) |
Outer Dimension | 1631mm(L)*774 mm(W)*1208 mm(H) |
Conveyor Speed | 0.22 m/s |
Conveyor Max Load | 150 KGS |
Single inspection dosage | < 1.32 μGy |
Wire Resolution | 0.0787 mm metal line |
Steel Penetration | 10 mm |
Film Safety | For ISO 1600 |
Maximum leakage radiation | <0.3 µGY/H |
X-ray Generator
Orientation | Upward |
Tube Current | 0.3~0.8 MA(adjustable) |
Anode Voltage | 80 KV(adjustable) |
Angle | 60° |
Cooling: | Sealed oil bath with forced air |
Duty Cycle | Rated for 100% Duty Cycle |
Operating Environment
Work Temp/Humidity | 0℃~ +45℃/20%~95% non-condensing |
Storage Temp/Humidity | -20℃~ +60℃/20%~95% non-condensing |
Voltage: | 220VAC(±10%) 50±3 Hz |
Power Loss: | 1.0KW(MAX) |
Noise | < 55 DB |
Image Processing system
1 X-ray sensor: L-shaped photodiode array detector (single energy), 24bit depth
2 Display: High-resolution 19 inch color LCD display
3 Edge enhancement: Object contour edge is more distinct
4 Super image enhancement: Image detail is more distinct
5 Magnifier: Partial magnifying function
6 Brightening/dimming: Increase/Decrease brightness of image
7 Image recurrence: Display all the the previous images and process any one of them
8 Image restoration: Restore image to initial status
9 Image storage: Real-time store any image and process it in operation status
1. Airports;
2. Banks;
3. Commercial buildings;
4. Courthouses;
5. Embassies;
6. Government buildings;
7. Military installations;
8. Prisons;
9. Ships;
10.Security checkpoints.
