Place of Origin: | China |
---|---|
Brand Name: | SECUERA |
Certification: | CE,FCC,ROHS,ISO9000 |
Model Number: | SE5030A |
Minimum Order Quantity: | 1 pic |
Price: | $0-1/pic |
Packaging Details: | Wooden Packing |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram,Paypal |
Supply Ability: | 100 pcs per day |
Sensitivity: | High Sensitivity | Charger Voltage: | 9V For AC Or 10V For DC |
---|---|---|---|
Working Hours: | 40 Hours Continuously | Application: | Electronic,Security,Quality Inspection |
Model Number: | SE5030A | Customize: | Support |
Features-1: | Alarm By Sounds & Light | Features-2: | Network Interface |
Features-3: | Safety Ray | Features-4: | Turn Off By A Key Control |
High Light: | x ray baggage scanner,airport baggage x ray machines |
Feature:
Alarm by sounds & light: Alarm by sounds and light when conform to condition
Network interface: Could be connect local area network and support multi-terminal check baggage at same times
Safety ray: Transmit ray under auomatic control, avoids the miss
Image monitoring for
user-friendly :
The monitor use fold, rotary system, operations adjusts the monitor position willfully according to own need, reduces wearily.
Simple operation by mouse:
Without keyboard and work table,control by mouse,save space.
Turn off by a key control : Turn off the machine only need one step: revolves the key. The equipment automatic security close-down, does not need complex many steps, is simpler
Eagle-eye: Could be expediently observing enlargement area
Estimate malfunction by self : Automatic estimate malfunction and prompt message, helpful for the maintenance
Image performance system:
X-ray sensor: L type photo-diode array detector,12 bit
Monitor: High resolution 17inch color LCD display
Color quality : 24 bit real color
Edge enhancement: Object contour edge is more distinct
Super image enhancement: Image detail is more distinct
High penetrate strength display: Increase brightness of dark area in Image to display object which is behind high absorptivity mass distinctly
Low penetrate strength display: Increase contrast of low absorptivity mass (easy to penetrate)to display it distinctly
Magnifier: Function of partial enlargement
Drightening /dimming : Increase brightness of image/decrease brichtness of image
Image recurrence: Display previous twenty images and process any one of them
Image restoration: Restore image to intial status at the time of stopping conveyor
Image storing : Real time store any image and process it in operation status
Muti-energy function:
Muti-energy color: Display organic material for orange, display inorganic material for blue, and display mixture for green
High energy/low enercy: Switch to display two energy type, high energy stands for metal etc. , low energy stands for nonmetallic
Auxiliay function for drugs & explosives:
Help to detect such dangerous material as drugs & explosive etc.
Audible & visible alarm : Give sound and visible signal when conform to condition
Technical data:
Tunel Size: 500(W) x 300 (H) mm
Conveyor speed: 0.22m/s
Conveyor Max Load : 20kg
Single inspection dosage: <1.5u Gy
Wire Resolution: 0.1mm metal line
Steel penetration: 8mm armor plate
Film Safety: For ISO 1600
Maximum leakage radiation: <0.3u GY/H
X-ray generator:
Orientation: Vertically Upward
Tube Current: 0.4-0.5MA(adjustable)
Anode Voltage: 80 KV(adjustable)
Angle: 60'
Generator cooling/working periods : Sealed oil bath with forced air/100%
