Sound / Light Alarm X Ray Parcel Baggage Scanner Public Traffic System Long Lifespan

Basic Information
Place of Origin: China
Brand Name: SECUERA
Certification: CE,FCC,ROHS,ISO
Model Number: SE-5030C
Minimum Order Quantity: 1 pic
Price: negotiable
Packaging Details: Wooden Box
Delivery Time: 5-8 workdays
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 300 pic /Month
Detail Information
Warranty: 3 Years Product Name: Traffic Road Blocker
Life: Over 10 Years Material: 304 Stainless Steel
Application: Factory,School,Prison,Car Parking Station And So On Model Number: SE-5030C
Feathers-1: Dangerous Objects(TIP) Insertion Feathers-2: Mass Storage
Feathers-3: One-key ON/OFF Feathers-4: Environmental Protection Design
High Light:

airport x ray scanner


portable digital x ray machine

Product Description

X-ray parcel scanner public traffic system baggage scanner exhibition x-ray security inspection machine



parcel x-ray scanner Unique features
1. Sound and light alarm: When conditions are met, there are sound and light alarm.
2. X-ray is safer: Automatically control the X-ray emission to avoid false emissions.
3. Humanized monitoring: According to operator’s needs, they can arbitrarily adjust the location of displayer which can be folded 360° to reduce fatigue.
4. Leading technology: Adopting parallel transmission technology, the speed of network transmission is 10-20 times faster than similar product.
5. Fault self-check: Automatically judge fault, and give prompt information for maintaining.
6. Automatic design: Device can automatically induct objects, and if it has something on it, machine will start automatically. If it has nothing on it, device is still.
7. Energy-saving design: Device is equipped with temperature induction control system. When the temperature of the device is too high or too low, the cooling fan can be automatically turned off or turned on to save energy and control the power consumption.
8. Environmental protection design: Lead curtain adopts new film pressing technology to prevent people from being exposed to lead and being polluted.
9. One-key ON/OFF: Click start button to turn on device. When rotate the key to turn off device, it will automatic safety shutdown, which can reduce failure.
10. Mass storage: Pictures are directly stored on the hard disk which can store more than 1 million pictures.
11. Dangerous objects(TIP) insertion: An image in dangerous objects image database are randomly injected into the image generated by scanning for operator to identify dangerous objects. (The function is optional)
parcel x-ray scannerTechnical Parameters


parcel x-ray scanner General indicators
Channel Size 500*300
Conveyor speed 0.22m / s
Maximum load conveyor belt 160kg
Resolution 0.0787mm diameter wire
Penetration 43mm steel plate
Film Safety safety film on the ISO1600
Leakage dose <0.18μGy / h
Single dose of checking ≤1.9 µGy


parcel x-ray scanner X-ray generator
Tube current 0.4mA ~ 0.5mA
Tube voltage 100 ~ 160KV
Beam divergence angle 60 °
Cooling Sealed oil cooling
Duty cycle 100%
X-ray sensor L-shaped photodiode array detector
parcel x-ray scanner Penetrating
Color / black and white images color / black and white image switch
Take away organic, inorganic, mixture removed
Image Sharpening edge sharpening effect
Image Zoom magnification effects
Image brightness enhancement image brightness highlighting one


parcel x-ray scanner Level
Image refinement increased image detail
Image Search Image playback search
Alarm The alarm can not penetrate or suspicious objects
Pull back the image display images passed
Operating temperature / humidity 0 ℃ ~ 45 ℃ / 20% ~ 95% (no condensation)
Storage temperature / humidity -20 ℃ ~ 60 ℃ / 20% ~ 95% (no condensation)
Operating voltage 220VAC (± 10%)
Power consumption 1.0KW (max.)
Noise level <55dB
